Description
Main Data:
General indicators
Frequency range: 400 ~ 480MHz
Number of channels: 40
Dimensions: 144.5*67.5*39mm
Weight: 284g
Channel spacing: 6.25KHz12.5KHz/25KHz.
Frequency stability: ±2.5ppm.
Antenna impedance: 50Ω.
Working voltage: Rated DC7.4V.
Battery capacity:2200mAh (lithium battery).
Receiver
Receiver sensitivity: ≤0.2μV
Adjacent channel selectivity: 60dB
Clutter response: ≥60dB
Rated audio distortion: <5%
Audio output:≥500mW
Environmental indicators
Working temperature: -30°C~+60°C
Storage temperature: -40°C ~ +85°C
Transmitter
Transmit power:10W
FM modulation method: F3M
Adjacent channel power: 60dB
Max Frequency Deviation: ±5KHz
Audio distortion: <5%
Default shipping UHF 400-480 Mhz,.
VHF 136-174 Mhz/245 Mhz/350-390 Mhz is also supported, please contact us if you need a VHF 136-174 or 245 Mhz or 350-390 Mhz. OEM/ODM all are acceptable .
Main Function:
➤Out Power 10w ➤16 Channels ➤TOT Function ➤Battery Save ➤PC Programming ➤Push to Talk
➤Single/Group Call ➤Low Battery Alert ➤SQL AND VOX function➤FM function ➤Wide/Narrow band Function ➤Support Analog/Digital Tone CTCSS/DCS
Main Accessories:
Radio Charger Antenna Battery
